For Architects & Specifiers
Elastomeric Stucco Systems Engineered for Architects
Stuc-O-Flex delivers high-performance elastomeric wall systems with verified performance data, complete specification resources, and a 40-year history of protecting landmark buildings. Our systems are engineered to provide superior crack resistance and advanced moisture management, ensuring your design integrity endures.
Engineered Flexibility
Long-Term Wall Performance Through Engineered Flexibility
Buildings are not static. They move, settling under load, flexing with the wind, and responding to thermal expansion and contraction. Traditional, rigid cement stucco resists this natural movement, inevitably leading to cracks that compromise the building envelope and your design. This failure is not a defect; it is a limitation of the material itself.
Stuc-O-Flex was engineered to solve this fundamental problem. Our elastomeric acrylic finish is not a simple coating but the key component of a complete wall system designed for dynamic performance. With an ASTM-tested elongation of 105%, our finish flexes with the structure, maintaining a continuous, crack-free surface that protects the building from water intrusion and preserves its aesthetic for decades.
In coastal and high-moisture environments, Stuc-O-Flex systems also provide enhanced resistance to salt spray exposure and weathering, helping preserve finish integrity and appearance over time. Our use of calcium carbonate fillers, rather than silica-based aggregate commonly found in competing systems, contributes to a smoother, more stable finish profile without the long-term concerns associated with harsher aggregate systems.
ASTM Test Results
Tested Performance, Documented
Stuc-O-Flex Elastomeric Acrylic Finish
- Elongation: 105%
- Salt spray resistance: 300 hours, no deleterious effects (ASTM B-117)
- Accelerated weathering: 2,000 hours, no deleterious effects (ASTM G-23-81)
- Fire rating: Class A (ASTM E-84)
- Water vapor transmission: 10 to 14 perms (ASTM E-96)
- Water penetration: no penetration on substrate (ASTM E-331)
- Freeze-thaw: 60 cycles, no cracking or checking
WaterWay 7mm Rainscreen
- Exceeds ICC/IRC AC-38 acceptance criteria for weather-resistive barriers
- Drains water 50 times faster than standard WRBs
- Maintains 90% open space within the drainage plane
- Vapor transmission exceeds 247 perms (ASTM E-96)
- Hydrostatic resistance: 10 cm at 18 hours, equivalent to 70-mph wind (AATCC 127)
Landmark Projects
Proven Performance Since 1988
For over 40 years, leading architects have specified Stuc-O-Flex for projects where performance, durability, and reputation are non-negotiable. Our systems are field-proven on complex institutional, commercial, and cultural buildings across every climate zone in North America and beyond. This track record provides the ultimate assurance that the assemblies you specify today will perform for years to come.
Bing Concert Hall, Stanford University
UCLA, Dormitory Housing
Virginia Tech, Center for the Arts
Hilton Hotel, Anchorage
University of Washington, Guthrie Hall
Vidorra Condos, San Antonio
Yeosu Exhibition Center, South Korea
System Engineering
Complete System Engineering, Not Just a Finish Coat
A wall’s performance is defined by its entire assembly, not just the outermost layer. We engineer integrated wall solutions that manage the forces of nature from the substrate out. Each component, from the base coat and reinforcing mesh to the finish and drainage mat, works in concert to deliver structural resilience and superior moisture control.
This system-based approach includes the pioneering WaterWay Rainscreen Mat, which creates a dedicated, continuous drainage and ventilation cavity behind the cladding. This vital space allows incidental moisture to drain harmlessly away and promotes drying within the wall cavity, preventing the moisture-related failures common in other systems. WaterWay exceeds ICC/IRC AC-38 acceptance criteria, drains 50 times faster than standard weather-resistive barriers, and maintains a 90% open drainage cavity.
Explore the WaterWay Rainscreen Mat
Review Our Wall Assembly Techical Gudies
Support Materials
Specification Resources
Everything your team needs to specify, detail, and inspect a Stuc-O-Flex assembly lives in the Stuc-O-Flex resource library. Direct links by document type:
Wall Assemblies
Complete assembly drawings and specifications.
Product Data Sheets
Technical specifications and performance data.
Specifications
BIM, CAD & Drawing Details
Warranty & Maintenance
Coverage details and care documentation.
Colors & Textures
Color palette, finish options, and textures.
Technical Support
Direct Technical Support for Your Projects
Your project deserves expert support. Our dedicated technical team is available to partner with you from initial design through construction administration. We provide project-specific guidance, answer complex specification questions, and offer responsive support to ensure your wall systems perform exactly as engineered.
Headquarters
Redmond, Washington
15459 NE 95th St,
Redmond, WA 98052
Eastern Division
Knoxville, Tennessee
40+
Years of continuous production and field-validated refinement.
